Orbea Carpe 20

Orbea Carpe 20
  • Color: Night Black Gloss
  • Color: Urban Green Gloss/Black Matte
  • Color: Blue Gloss/Black Matte
Please select options


You have a style, and you know what fits. Combine it in a certain way with the Carpe. These bikes are lightweight, versatile, and comfortable. There is beauty when you feel the handlebars, the smoothness of the gear change, or the harmony of its parts. You'll like your city and its streets even more while moving on two wheels. Nobody can stop you. These are the bikes that give you the freedom you've been waiting for. Throw a leg over and enjoy.

- Light aluminum frame with alloy fork
- 9-speed Shimano Altus components
- Shimano hydraulic disc brakes

WARNING: Cycling can be dangerous. Bicycles and bicycle products should be assembled and serviced by a professional mechanic. Never modify your bicycle or accessories. Read and follow all product instructions and warnings including information on the manufacturer’s website. Inspect your bicycle before every use. Always wear a helmet.


Frame Orbea Urban Speed, Aluminium 6000, Orbea Tube Shaping, Flat Mount Disc Brake, 135x9 QR, Carrier and Mudguard compatible, max 700x40C, Inner Cable routing,
Fork Speed 400mm Alloy Flat mount
Headset VP-Z104PD 1-1/8" Semi-Cartridge
Rims/Wheels Orbea Airline Corsa Disc 700X19c
Tires Kenda K1067 700x38C Reflective type+puncture protection
Crankset Orbea Alloy 42t
Chain Shimano HG53 9-Speed
Rear Derailleur Shimano Altus M2000 SGS Shadow
Rear Cogs Sun Race CSM989 11-36t 9-Speed
Shifters Shimano SL-M2010
Handlebars Alloy 31.8mm Riser 640mm
Stem Alloy 31.8mm interface 7º
Brake Levers Orbea Trekking Alloy 4-finger
Brakes Shimano MT200 Hydraulic Disc
Saddle Velo 1221
Seat Post Alloy 27.2 Offset 0
Accessories & Extras We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colors, and materials.

* Subject to change without notice.

Part Numbers

Option UPC MPN Store SKU
Night Black Gloss / X-Small 8434446761645 L40143S9 ORB17228233N
Night Black Gloss / Small 8434446761683 L40148S9 ORB16299993N
Night Black Gloss / Large 8434446761768 L40156S9 ORB16582723N
Night Black Gloss / X-Large 8434446761805 L40158S9 ORB17737566N
Blue Gloss/Black Matte / Medium 8434446761751 L40153SC ORB19203991K
Blue Gloss/Black Matte / Large 8434446761799 L40156SC ORB19583427K
Blue Gloss/Black Matte / X-Large 8434446761836 L40158SC ORB20654326K
